Providing a new path to the future of agriculture
The Darwin S is a mechanical thinning unit without a support/mounting. It is our flexible thinning unit and can be mounted in different ways. It is used on already existing machines in the vehicle fleet.
Darwin Solo
Blossom Thinner
The Darwin S is mounted with the spindle in the direction of travel. The rotor carrier has a slight angle to the right towards the trees. Due to its design, the machine is always mounted with the spindle in the direction of travel, so a better view of the spindle is ensured and thus you can guide more easily the spindle on / in the tree crown / mold.
|
Darwin 150 |
Darwin 200 |
Darwin 230 |
Darwin 250 |
Darwin 300 |
|
|
Working Height (m / ft) |
1.475 / 4'10" |
1.935 / 6'5" |
2.245 / 7'5" |
2.395 / 7'10" |
2.850 / 9'5" |
|
Machine Height (m / ft) |
1.820 / 6' |
2.285 / 7'6" |
2.580 / 8'6" |
2.740 / 9' |
3.200 / 10'6" |
|
Weight (kg / lbs) |
87 // 192 |
90 // 198 |
93 // 205 |
96 // 212 |
101 // 223 |
|
String Bars |
18 |
24 |
30 |
30 |
36 |
|
Area Performance |
1.5 - 2.5 ha/h |
||||
|
Driving Speed |
6 - 18 km/h |
||||
|
Spindle Speed (RPM) |
150 - 450 1/min |
||||
|
String Length |
60 cm |
||||
|
Required Oil Quantity |
25 I/min |
||||
|
Max. Working pressure |
210 bar |
||||
|
Tractor Mounting |
To already existing basic unit / working tool |
||||
